Láser de fotoestimulación veterinaria para équidos GBOX PLUS

para caballosnómadapara la rehabilitación

Overview
Non-invasive Class 4 Laser Therapy that penetrates deep into tissues to accelerate healing, reduce inflammation and assist equine athletes to recover faster. Multi-wavelength device architecture enables treatment of both superficial and deep tissue conditions in horses.

Ideal for

• Post-race recovery
• Tendon injuries
• Arthritis
• Pain management
• Preventive care

Key benefits

• Non-invasive & painless treatment alternative to injections or surgery
• Accelerates healing and enhances performance by reducing inflammation and promoting tissue repair
• Reduces pain and improves flexibility, enabling faster return to competition
• Short treatment times (typical sessions 5–15 minutes)

Product highlights

• Powerful and portable system (GBOX PLUS)
• High-power Class 4 laser technology for deep tissue therapy
• Multi-wavelength configuration for optimized tissue penetration and circulatory/ATP effects
• Smart handpiece for easy operation and multiple optics
• Suitable for racehorse facilities, veterinary clinics and equine care centers
• Available in 4- or 5-wavelength configurations: 1064nm + 980nm + 915nm + 810nm + 635nm
• Operating modes include Continuous Wave (CW) and Intense Superpulse (ISP)

Features

• Create and save personalized treatment protocols per patient (customizable protocols and unlimited patient history data)
• 4/5 wavelengths: 1064nm (deep penetration), 980nm (improves circulation), 915nm (enhances oxygen delivery), 810nm (increases ATP production), 635nm (targets superficial receptors)
• Intense Superpulse (ISP) mode: variable duty-cycle pulsing to stimulate deeper tissues while allowing cooling intervals to reduce burn risk; promotes ATP production, collagen synthesis and improved blood circulation
• Powerful battery management: full power ~1 hour; low power up to ~4 hours; changeable battery; also supports extended stationary operation modes
• Smarter software operation: 10.1-inch HD touchscreen on Android platform, Wi‑Fi enabled updates; quick selection of treatment parameters by condition/BMI/skin tone
• Five handpiece optics included: 30mm open zoom lens, 30mm curved contact lens, 10mm curved contact lens, 5mm TMJ lens, 30mm 360° rolling large massage-ball lens

Media
Device is documented with product imagery and a product demonstration video; technical brochure is available in PDF format.

Caractéristiques / Spécifications techniques

• Wavelength combinations (nm): 1064nm + 980nm + 915nm + 810nm + 635nm
• Wavelength selectability: Any combinations with independent control
• Frequencies: 0.2 to 20,000 Hz & ISP
• Intense Superpulse Peak (ISP): 55W + 2000mW (635nm)
• Continuous Wave Power (CW): 40W + 2000mW (635nm)
• Diode: High-powered solid-state diode module
• Technology platform: 10.1 inch HD touch screen; Android platform; Wi‑Fi enabled software updates
• Dimensions (handpiece): 265(W) * 270(L) * 120(H) mm
• Weight: 4.2 kg without battery; 4.8 kg with battery
• Battery: Full power ~1 hour; low power up to ~4 hours; changeable battery; supports extended stationary operation
• Handpiece optics: 30mm open zoom lens; 30mm curved contact lens; 10mm curved contact lens; 5mm TMJ lens; 30mm 360° rolling large massage ball lens
• Laser cable: fibers of 400 µm and 600 µm with SMA905 connector
• Folding screen: Yes
• Shoulder sling / Portable: Yes
• Customizable protocols: Yes
• Unlimited patient history data: Yes
• Pain scale, BMI tone and skin tone selection: Yes
• Clinical support capability: Yes
