Láser para lesiones vasculares LASEVIA

para el rejuvenecimiento vulvovaginalpara lipólisispara bioestimulación ortopédica

Product overview
LASEVIA is a multi-wavelength diode laser platform (portable console) combining selectable semiconductor sources for aesthetic, vascular and therapeutic medicine. Platform supports multiple factory configurations and up to 30 W+ peak output across clinical specialties; Class 4 device with 11.6" Android smart touchscreen.

Key platform features
Multi-wavelength architecture: selectable diode wavelengths mapped to specific chromophores (water, haemoglobin, lipid, melanin). Up to 4 wavelengths per configuration. Peak output up to 30 W+. Portable console ~15 kg with single-handle carry frame. Safety hardware includes emergency laser stop and mechanical safety shutter.

Clinical specialties (Eight specialties)

• Endolifting — deep 1940 nm fractional fiber for non-surgical lifting (face, neck, body)
• Lipolysis — ring-light fiber emulsifies adipose via micro-cannulas for mini-invasive body contouring
• Spider vein & Vascular — transdermal and endovenous coagulation of telangiectasia and varicose veins
• Therapy · HILT Class IV — deep-tissue photobiomodulation for pain, inflammation and tissue repair
• LVR — non-ablative 635 nm vaginal rejuvenation and intimate-health protocols
• Proctology — fiber-delivered coagulation for haemorrhoids and fistulas (mini-invasive)
• EVLT — endovenous laser ablation of varicose veins (1470 / 1940 nm)
• ENT — 450 nm blue diode for minimally invasive ENT soft-tissue surgery

Wavelengths & clinical mapping
450 nm: ENT (8 W in config B)
635 nm: LVR, surface vascular, therapy (500 mW or 2 W depending on configuration)
980 nm: Therapy, Proctology, Vascular (up to 30 W in config B; 20 W in config A)
1470 nm: Lipolysis, EVLT (15 W typical)
1940 nm: Endolifting, EVLT (10 W in config A)

Factory configurations (summary table)
Configuration A: 1940 nm 10 W · 1470 nm 15 W · 980 nm 20 W · 635 nm 500 mW · fiber core 200 µm
Configuration B: 1470 nm 15 W · 980 nm 30 W · 450 nm 8 W · 635 nm 2 W · fiber 200 / 400 µm

Delivery, handpieces & accessories

• Universal SMA905 fiber interface accepts contact fibers 200 / 400 / 600 / 1000 µm and non-contact tips
• Handpiece sets: Basic Handpiece Set (endolifting, lipolysis), Advanced Liposuction Set, SUPERSCAN Focus Set (spider vein / fractional), LVR Handpiece Set, PM5 Therapy Set, Disposable LVR Set, Disposable Surgical Set
• Fiber types: High-Power Fiber (SMA905), Bare Fiber (direct contact), Polyimide Fiber, Radial Fiber (360° emission), Hemorrhoid Fiber (typically 600 µm)
• Accessories: Laser safety goggles, foot switch, fiber cutter, fiber stripper, connector cleaner

Emission & pulse capabilities
Emission modes: CW · single pulse · repeat pulse
Pulse width: 25 µs – 10 s
Repetition rate: 0.05 Hz – 50 kHz

Interface & usability
11.6" Android smart touchscreen with touch presets, real-time energy readouts and one-tap protocol recall. Four professionally tuned UI themes ship on the device.

Clinical notes & performance
Platform intended to replace multiple single-purpose devices by switching wavelength and delivery set for different indications. EVLT protocols shown with high occlusion rates in clinical contexts; endolifting uses 1940 nm fractional fiber for deep and superficial remodeling. Specifications are configuration-dependent.

caractéristiques / spécifications techniques

• Laser type: Multi-wavelength semiconductor (diode) laser platform
• Wavelengths: 450 / 635 / 980 / 1470 / 1940 nm — configuration dependent
• Maximum output: Up to 30 W+
• Configuration A (example): 1940 nm 10 W · 1470 nm 15 W · 980 nm 20 W · 635 nm 500 mW · fiber 200 µm
• Configuration B (example): 1470 nm 15 W · 980 nm 30 W · 450 nm 8 W · 635 nm 2 W · fiber 200 / 400 µm
• Emission modes: CW · single pulse · repeat pulse
• Pulse width: 25 µs – 10 s
• Repetition rate: 0.05 Hz – 50 kHz
• Delivery system: SMA905 fiber interface · contact fibers 200 / 400 / 600 / 1000 µm · non-contact tips
• Interface: 11.6" Android smart touchscreen
• Safety: Emergency laser stop · mechanical safety shutter · Class 4
• Power supply: 100 – 240 V, 50 – 60 Hz, 350 VA
• Weight: 15 kg (portable console)
• Certification: CE · MDSAP · ISO 13485 · FDA-cleared therapeutic laser lineage
